It utilizes a built-up CFS girt along the back face and CFS brace anchored to a nearby concrete core wall. The project includes a 10-foot-tall, 18-foot-wide, partially freestanding roof parapet wall. The smaller silo is located on the front canopy near the entrance and consists of two 7-foot-tall segments, each with four shear wall panels.įirst-Place Award -The Leffler Group-Pena Hyatt Place-Denver, Colorado The freestanding 50-foot-tall silo, built behind the store, consists of six stacks of three shear wall panels. was contracted to provide structural analysis and design for two exterior silos, trademarks of Stew Leonard’s, which feature curved cold-formed shear walls that are wrapped in two layers of plywood and finished with stucco. The Stew Leonard’s grocery chain operates stores along the Eastern Seaboard, but this site marks its first venture into New Jersey. On-the-spot solutions were required to meet installation and budget deadlines.įirst-Place Award / Commercial -raSmith-Stew Leonard’s-Paramus, New Jersey No two studs are alike at the top of the structure, which was the most difficult curve to achieve. The unusual curved shape was achieved using conventional CFS and proprietary curved framing as well as concave stud bracing. The bridge connects the new Ballston Mall to the Metrorail station. Structural steel tubes support a waving zinc roof which encloses an interior space surrounded by glass curtain walls, a polished concrete floor and a faceted wood-look ceiling.
The Ballston Quarter Pedestrian Walkway replaced the Festival Bridge across busy Wilson Boulevard. Two different trellises, located at the top parapet and a building corner, wrap two elevations and span across multiple panels.įirst-Place Award / Municipal -ADTEK Engineers, Inc.-Ballston Quarter Pedestrian Walkway-Arlington, Virginia The structure has 400 different prefabricated panels and 200 different prefabricated Stolite finish panels, all precisely dimensioned and fabricated to fit, like a puzzle.
The exterior utilizes prefinished prefabricated panels with all cold-formed framing and connection elements located dimensionally on the building. The modern mixed-use building is an eclectic mix of studio, 1-, 2-, 3- and 4-bedroom units.
Hub State Street is an 11-story luxury student housing option near Purdue University. We appreciate all the entries that were submitted.”įirst-Place Award / Residential/Hospitality -raSmith-Hub State Street-West Lafayette, Indiana “Our goal in conducting this competition is to share these solutions and stimulate new ideas for architects, engineers and other design professionals. “Cold-formed steel provides a cost-effective solution for a wide variety of construction projects,” said Robert Wills, P.E., managing director of the Cold-Formed Steel Engineers Institute. Information on the CFSEI Creative Detail Award winners are included on CFSEI’s website at.
WASHINGTON, DC -The Cold-Formed Steel Engineers Institute (CFSEI) has announced the winners of its 2020 CFSEI Design Excellence and Creative Detail awards.
